The Pedroll PK range of peripheral impeller booster pumps are robust, economical pumps principally used for water transfer in domestic applications where there is insufficient mains water pressure available. They can be installed for manual operation or for automatic control using either a pressure tank and switch or the unique Press- control control unit.
Motor
Pumps are close coupled to a TEFC brushless induction motor designed for continuous operation. A thermal relay is provided in the windings to protect against electrical and mechanical overload and the pump can be connected directly to the mains power supply through a 10amp fuse or MCB.
Specifications
Enclosure Class: IP55
Insulation Class: F
Standard Voltage: 1x240V
Speed: 2900rpm
OPERATING CONDITIONS
Pumped liquid: Thin, clean, chemically non-aggressive liquids without abrasive particles or fibres.
Max. Fluid Temperature: +60°C
Max. Ambient Temperature: +40°C
Max. Suction Lift: 7m (at sea level).
